638nm 300mW Red Fiber Coupled Laser CW/TTL/Analog

Starting at: $1,112.00

Please Choose:









Add to Cart:


638nm 300mW Red Fiber Coupled Laser CW/TTL/Analog

[Specifications]
Product Name: 638nm Fiber coupled laser
Lead Time: 2~3 Weeks
Output Wavelength: 638nm ±5 nm
Output Power: 300mW
Operating Mode: CW or Modulation
Power stability: <±3% per 4 hrs
Temperature Stabilizing: TEC
Warm Up Time: <2 minutes
MTTF(mean time to failure): 10,000 hrs
Fiber Core Diameter: 100μm/200μm/400μm/600μm/800μm/1000μm (Choose)
Fiber Numerical Aperture: 0.22NA(100μm~400μm)/0.37NA(600μm~1000μm)
Fiber Interface(Output): FC/PC, FC/APC, SMA905 (Choose)
Fiber Length: 1m/2m/3m (Choose)
Laser Head Dimension: Near 100(L)*40(W)*50(H)mm³ (fan adds height) (Click here find detail)
Power Supply: Split type power supply / Lab Adjustable power supply (Choose)
Power Supply-1: Split Power Supply (Choose) (Click here find detail)
Power Supply-2: Lab Adjustable Power Supply (Choose) (Click here find detail)
Modulation: 0~30kHz Analog or TTL
Warranty: 1 Year

[Package Include]
1 x 638nm Laser head
1 x Power supply
1 x Optical fiber

Note: The marked output power is before coupling, coupling efficiency is about 80%~90%.






CivilLaser laser product image

Output power adjustable:
dpss laser Output power adjustable
