473nm 10mW~200mW blue fiber laser with power supply Support customized

Starting at: $1,080.00

Please Choose:











Add to Cart:


473nm 10mW~200mW blue fiber laser with power supply customize fiber diameter & length

Fiber-coupled laser features:
1. The length of fiber can be customized.
2. You can change the direction of the laser beam, it can be applied to a variety of occasions venue.
3. Laser spot is circular, uniform illumination.
4. The laser fiber can be installed at the exit of the collimator lens care area to adjust the size, large or small.

Note:
1. It's made-to-order products, we need 1~3 weeks to produce it.
2. The output power/fiber diameter/fiber length can be customized.
3. The marked output power is before coupling, coupling efficiency is about 80%~90%.

[Specifications]
Product Name: 473nm fiber coupled laser with Power Supply
Product Include: Laser system with fiber + Controller + Power source
 Output Wavelength: 473nm±2nm
Output Power: 10mW~200mW(Choose)
Operating Mode: CW or Modulation
Power Stability:  <±5% per 2 hrs
Temperature Stabilizing: TEC
Warm Up Time: <5 minutes
Optimum Operating Temperature: 20~30℃
Storage Temperature: 10~50℃
MTTF(mean time to failure): 10,000 hrs
Fiber Type: Multi-mode fiber/MM fiber
Fiber Core Diameter: 105μm/200μm/400μm/600μm/800μm/1000μm (Choose)
Fiber Numerical Aperture: 0.22NA(100μm~400μm)/0.37NA(600μm~1000μm)
Fiber Interface(Output): FC/PC, FC/APC, SMA905 (Choose)
Fiber Length: 1m/2m/3m (Choose)
Laser Head Dimension: Near 100(L)*40(W)*50(H)mm3 (fan adds 15mm height) (Click here find detail)
Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)
Power Supply-1: Standard Power Supply (Choose) (Click here find detail)
Power Supply-2: Lab Adjustable Power Supply (Choose) (Click here find detail)
Modulation: 0~30kHz Analog or TTL
Warranty: 1 Year

[Application]
Thermal printing
Material Inspection
Scanning Biochemistry
Lidar

[Package include]
1 x 473nm fiber laser
1 x Laser power supply
