1085nm 500mW Infrared DPSS Laser Diode Pumped Laser System

1085nm 500mW Infrared DPSS Laser Diode Pumped Laser System

[Specifications]
Product Name: 1085nm DPSS laser
Output Wavelength: 1085nm±5nm
Spatial Mode: Near TEM00
Output Power: 500mW
Operating Mode: CW or Modulation
The Polarization Direction: Linear
Pointing Stability: <0.05 mrad
Beam Diameter(1/e²): Near 3 mm
Beam Divergence (Full Angle): Near 2 mrad
Beam Height: Near 29mm
Beam Quality(M2): <2
Power Stability: <±5% per 2 hrs
Temperature Stabilizing: TEC
Working Temperature: 20~30℃
Storage Temperature: 10~50℃
Warm Up Time: <5 minutes
Laser Head Dimension: Near 155(L)x77(W)x60(H)mm³(Click here find detail)
Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)
Power Supply-1: Standard Power Supply (Choose) (Click here find detail)
Power Supply-2: Lab Adjustable Power Supply (Choose) (Click here find detail)
Modulation: 0~30kHz Analog or TTL
MTTF(mean time to failure): 10,000 hrs
Warranty: 1 Year

[Packing List]
1 x 1085nm DPSS laser
1 x Power supply
