1064nm 10W High Power IR DPSS Laser Diode Pumped Laser

[Specifications]
Product Name: 1064nm DPSS laser
Output Wavelength: 1064nm±1nm
Spatial Mode: Near TEM00
Output Power: 10W
Operating Mode: CW or Modulation
Polarization: 100:1
Pointing Stability: <0.05 mrad
Beam Diameter(1/e²): <3 mm
Beam Divergence (Full Angle): <1.5 mrad
Beam Height: Near 68.2mm
Beam Quality(M2): <2
Power Stability: <±3% per 2 hrs
Temperature Stabilizing: TEC
Warm Up Time: <10 minutes
Laser Head Dimension: Near 200(L)x99(W)x94(H)mm³(Click here find detail)
Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)
Power Supply-1: Standard Power Supply (Choose) (Click here find detail)
Power Supply-2: Lab Adjustable Power Supply (Choose) (Click here find detail)
Modulation: 0~30kHz Analog or TTL
MTTF(mean time to failure): 10,000 hrs
Warranty: 1 Year

[Packing List]
1 x 1064nm DPSS laser
1 x Power supply
