658nm 200mW Pigtailed Laser Red Laser Diode Fiber Coupler

[Specifications]
Product Name: 658nm pigtailed laser
Wavelength: 658±10nm
Output Power: <200mW
Output Mode: Multimode
Multimode Coupling Ratio: >90%
Spot Form: Astigmatism
Fiber Core Diameter: 200μm
Fiber Length: 1m (Customizeable)
Fiber Interface Type: FC/SMA905/LC/SC (Choose)
Fiber Material: Quartz
Coupling Lens Material: Optical glass
Operating Voltage: DC 2.4V
Operating Voltage With Power Diver: DC 3-5V
Operating Current: <300mA
Circuit Control Mode: ACC / TTL frequency modulation (Choose)
Operating Temperature: -10~70℃
Storage Temperature: -40~85℃
Size: Φ20*70mm
