650nm 100mW Red Pigtailed Laser Multimode Fiber Coupled Laser

Starting at: $190.00

Please Choose:









Add to Cart:


650nm 100mW Red Pigtailed Laser Multimode Fiber Coupled Laser

[Specifications]
Wavelength: 650±10nm
Output Power: <100mW
Output Mode: Multimode
Multimode Coupling Ratio: >90%
Spot Form: Astigmatism
Fiber Core Diameter: 200um
Fiber Length: 1m (Customizeable)
Fiber Interface Type: FC/SMA905/LC/SC (Choose)
Fiber Material: Quartz
Coupling Lens Material: Optical glass
Operating Voltage: DC 2.2V
Operating Current: <160mA
Operating Voltage With Power Diver: DC 3~5V
Circuit Control Mode: ACC / TTL frequency modulation (Choose)
Operating Temperature: -10~60℃
Storage Temperature: -20~85℃
Size: Φ6*16mm

Wiring instructions: https://www.civillaser.com/news/red-pigtailed-laser-with-ttl-drive-circuit-1581/
