638nm 1200mW Orange-red Laser Module With TTL Modulation

$332.00

Add to Cart:


638nm 1200mW Orange-red Laser Module With TTL Modulation


This module can be widely used in all kinds of stage laser light, with TTL modulation, can work for a long time, it's a real industrial grade laser.

SPECIFICATIONS:
Name:  638nm 1200mW Laser Module
Wavelength: 638nm
Output power: 1200mW
Surface Treatment:  Blue
Shell Material:  Aluminum + copper
Circuit Control:  12V Buck Constant Current
Reverse Protection:  Yes
Operating Voltage:  DC=12V
Operating current:  I<1200mA
Warm-up time:  0
Working Temperature:  -10℃ ~ +40℃
Storage Temperature:  -10℃ ~ +40℃
Cooling Mode:  Aluminum heat dissipation
Modulation Frequency: Tunable
Structure: laser tube + lens + heat dissipation shell
Laser Size: 69mm*30mm*30mm(L*W*H)
Circuit Size:  47.5mm*35.5mm*20mm(L*W*H)




638nm 1200mW Laser Module

638nm 1200mW Laser Module

638nm 1200mW Laser Module

638nm 1200mW Laser Module

638nm 1200mW Laser Module

638nm 1200mW Laser Module
