SMA Multimode Metal Fiber Optic Connector

$6.00

Add to Cart:
Min:  10

SMA Multimode Metal Fiber Optic Connector

SMA fiber optic connector is usually used in optic fiber communications system for some special occasions such as testing equipment, data network, military instrument and medical devices. This fiber optic component usually comes with two types of ferrule, which are ceramic and metal. Metal ferrules are typically utilized in SMA905 and SMA906 fiber optic connectors.

[Features]
1. Corrosion resistant and durable
2. Ceramic, metal and plastic ferrules are available.

[Applications]
1. CATV
2. Active devices
3. Medical instruments
4. Optical fiber communication system
5. Telecommunication network
6. LANs
7. WANs

Specifications of SMA Fiber Optic Connectors

Parameter Specifications
Multimode fiber connector
Ferrule Material Metal or ceramic
Insertion Loss Metal ferrule: Typical≤0.60dB, max.≤1.00dB Ceramic ferrule: Typical≤0.20dB, max.≤0.30dB
Ferrule External Diameter ∮3.15mm
Ferrule Size Pore size: 127+3/-0μm, concentricity≤3.0μm
Operating Temperature -20℃ to +70℃
Storage Temperature -40℃ to +85℃
SMA Multimode Metal Fiber Optic Connector

SMA Multimode Metal Fiber Optic Connector

SMA Multimode Metal Fiber Optic Connector

SMA Multimode Metal Fiber Optic Connector
