520nm 150mW Powell 0.2mm Linewidth Uniform Green Line Laser Diode Module 16x90mm

520nm 150mW Powell 0.2mm Linewidth Uniform Green Line Laser Diode Module 16x90mm

[Features]
Utilizing an original imported Powell prism, it produces a uniform, straight line with no bright spots at either end.
A 1-12V adjustable power supply is included, allowing for easy brightness adjustment.
The wire width is adjustable externally for simple and convenient use; the wire position remains unchanged during adjustment, ensuring precision and reliability. After adjusting the wire width, the locking knob can be used to lock the lamp head, providing shock and drop protection.
Wire width is adjustable from 0.08 mm to several centimeters to meet various usage requirements.
Powell prism angles are available from 5° to 120°.
Exceptionally high stability, suitable for 24/7 operation.
Equipped with an imported IC intelligent driver board, it supports a wide range of power supplies; other voltages can be customized.
Internal filling with thermal silicone and AB glue ensures excellent heat dissipation and shock and drop protection.
The outer shell is made of aviation-grade aluminum with an insulating varnish, providing excellent heat dissipation, shock and drop protection, and anti-static properties.
High-temperature resistant and corrosion-resistant wires are suitable for all-weather, all-encompassing use.

[Specification]
Product Name: Laser module
Wavelength: 520nm
Output Power: 150mW
Laser Shape: Line
Operating Voltage: DC 9-25V(Customizable)
Operating Current: ≤800mA
Line Width: Adjustable
Optical Lens: Original imported Powell prism
Lens Angle: 5°~120° (Customizable)
Operating Temperature: -20℃ ~ +70℃
Storage Temperature: -40℃ ~ +85℃
Size: φ16*90mm (Customizable)

Line Length:
Indoor working environment: Up to 30 meters.
In semi-outdoor (non-direct sunlight): Up to 12 meters.
In outdoor (direct sunlight): Up to 6 meters.
Installation Height: 0~15 meters.

Adjustable Line Width:
0.1m-0.3m: 0.2mm
0.3m-0.5m: 0.3mm
0.5m-0.8m: 0.4mm
0.8m-1m: 0.5mm
1m-1.5m: 0.6mm
1.5m-2m: 0.7mm
2m-2.5m: 0.8mm
2.5m-3m: 0.9mm
3m-4m: 1mm
4m-5m: 1.5mm

[Package Include]
1 x Laser module
1 x Power supply
1 x Module holder
