650nm 5mW Red Line Laser module 24V Horizontal reticle transmitter

650nm 5mW Red Line Laser module 24V Horizontal reticle transmitter

SPECIFICATIONS:
Name:  650nm 5mW Red Line Laser module 24V
Output Wavelength: 650nm ±5nm
Output Power: <5mw(can be choose)
Class level: Class IIIB
Laser Shape: Line
Range: <5 meters
Material: Copper+ aluminum
Surface treatment / color: black (black oxide)
Laser type: Red laser
Shape/dimension: Line, line width<1.0mm, <2mm at 1m distance
Fan angle: 36.5°，45°，60°，90°，110°(Optional, 90° is default,leave a comment if you need other fan angle)
Circuit control: APC
Size: Φ9x26mm, Φ10x30mm(default) , Φ12x30mm
Operating Voltage:  DC=24V
Operating current: I<40mA
Operating Temperature: -10°C~+50°C
Storage Temperature: -40°C~+80°C
Tail wire: 26# Red and black line, about 150mm long, power supply can be choose
Warranty: 12 Months Factory warranty

Package List：
1*Red line Laser Module；
