980nm 1310nm 1550nm Polarization Maintaining Pump Laser Protector Bare Fiber Without Connector
[Specification]
| Parameters |
Unit |
Value |
| Center Wavelength |
nm |
980 (1310nm,1550nm can be customized.) |
| Operating Wavelength Range |
nm |
±15 |
| Max.Insertion Loss |
dB |
0.60 |
| Min.Extinction Ratio |
dB |
20 |
| Blocked Wavelength Range |
nm |
1020~1080 |
| Min.Isolation @1030nm |
dB |
50 |
| Min.Return Loss |
dB |
50 |
| Connector Type |
|
None |
| Fiber Type |
|
PM980 fiber |
| Pigtail Type |
|
250μm bare tube |
| Fiber Length |
m |
1.0 |
| Max.Optical Power (CW) |
W |
1 |
| Max.Tensile Load |
N |
5 |
| Operating Temperature |
℃ |
-5 ~ +70 |
| Storage Temperature |
℃ |
-40 ~ +85 |
