780nm Femtosecond Pulse Fiber Laser Ultra-Fast Laser Desktop Type

$43,124.00

 Sold Out

780nm Femtosecond Pulse Fiber Laser Ultra-Fast Laser Desktop Type

The ultrafast laser adopts the latest femtosecond laser technology to achieve stable output of 780nm band femtosecond pulse laser. One-key auto-start and long-term stable operation. It has the characteristics of extremely narrow laser pulse and high pulse peak power. It has important applications in the fields of optical frequency comb, terahertz wave, and multiphoton imaging.

[Features]
Femtosecond pulse width.
Self-starting and maintenance-free.
Full polarization and high stability.

[Applications]
Multiphoton excitation imaging
Two-photon absorption
Ultrafast laser phenomenon

[Specification]

Parameter Unit Value Remarks
Wavelength nm 780±10
Spectral Width nm 20nm 20nm@3dB
Pulse Width fs 120 50/100/200/500fs Customizable
Output Power mW 300  Customizable
Power Instability   < 1%
Repeat Frequency MHz 80 Customizable
Repeat Frequency Instability Hz <100
Single Pulse Energy nJ >0.4
Laser Polarization   Linear polarization
Output Mode   Spatial Light
Preheat Time min <1

Electrical and environmental parameters

Parameter Desktop Type
(Current Product)
Module Type
Control Mode Button Button
Synchronous Electrical Signal Interface SMA SMA
Power Supply 100~240V AC, <30W 5V DC, <20W
Size 330(W)×398(D)×112(H)mm 200(W)×121(D)×55(H)mm
Operating Temperature 5 ~ 45°C
Operating Humidity 0~70%
