1310nm 1550nm 10mW SLD Broadband Light Source Customizable

$2,702.00

Add to Cart:


SLD Broadband Light Source 1310nm 1550nm 10mW Light Source Customizable

The SLD broadband light source uses semiconductor super-radiation diode technology to output a broadband spectrum with high output power. The operating wavelength can be selected from O, S, C, and L bands, which is suitable for applications such as fiber optic sensing. Can provide communication interface and host computer software to facilitate the monitoring of light source status.

[Fratures]
High power stability
Power adjustable
Flat spectrum

[Application]
Optical fiber sensing
Medical imaging
Optical fiber device test

[Speicfictaion]

Parameter

Unit

Typical value

Remarks

Spectral Range

nm

1310/1450/1550/1610

Optional

Output power

mW

10

Not adjustable by default

Power Adjustable Function

-

Adjustment range: 10% ~ 100%

Customizable

Spectral flatness

dB

10(Type)



Output end isolation

dB

>35



Short term stability(15Minutes)

dB

≤ ±0.02



Long-term stability(8Hours)

dB

≤ ±0.05



Degree of polarization DOP

dB

≤ 0.2



Pigtail connector

 -

FC/APC



Pigtail Fiber Type

 -

SMF-28e Singlemode fiber





Electrical and environmental parameters

DeskTop Type
(Current product)

Model Type

Control method

Button

RS232 Serial communication

Communication interface

DB9 Female
(Default not include)

DB9 Female

Power supply

100~240V AC, <30W

5V DC, <15W

Size

260(W)×280(D)×120(H)mm

125(W)×150(D)×20(H)mm

Operating temperature range

-5~+55°C

Operating humidity range

0~70%
