1064nm 100mW Picosecond Pulse Fiber Laser Ultra-fast Picosecond Pulsed Source Module Type PSPL-1064-25-100-20-PM-M
This ultrafast laser uses high-performance rare earth optical fiber as the working medium, combined with full polarization-maintaining mode-locking technology and active servo control system, to achieve stable output of picosecond pulse laser in the 1064nm band. It can be fully self-started and work stably for a long time, with the characteristics of narrow laser pulse and high pulse peak optical power. This light source can be used for scientific research in the fields of high-power laser, supercontinuum, laser ranging, etc.
*Accept customization of parameters such as pulse width, power, repetition frequency, etc.
[Features]
Ultrashort pulse.
Self-starting and maintenance-free.
Fully Polarization maintaining, high stability.
[Application]
Fiber laser pumping
Supercontinuum generation
Seed laser pulse
[Specifications]
|
Parameters
|
Unit
|
Typical value
|
Remarks
|
|
Model
|
-- |
PSPL-1064-25-100-20-PM-M |
|
|
Wavelength
|
nm |
1064 |
1030/1064nm customizable |
|
Spectral Width
|
nm |
1~2nm @3dB |
Customizable |
|
Pulse Width
|
ps |
≤25 |
10/20/50/100ps customizable |
|
Output Power
|
mW |
≥100 |
10~2000mW customizable |
|
Power Instability
|
-- |
< ±1% |
@6 hours |
|
Pulse Repeat Frequency
|
MHz |
20±1 |
Oscillator base repetition frequency
15~80MHz customizable |
|
Pulse Frequency Adjustable Range
|
-- |
Basic repetition frequency/N |
N=2/3/4/5...;
Acoustic and optical frequency reduction, as low as 1kHz.
|
|
Single Pulse Energy
|
nJ |
>1 |
|
|
Laser polarization state
|
-- |
Linear polarization |
|
|
Laser Output Method
|
-- |
PM980 polarization-maintaining fiber |
L=1m |
|
Fiber Interface
|
-- |
FC/APC |
Slow axis alignment |
|
Preheat Time
|
min |
<1 |
|
|
Electrical and Environmental Parameters
|
Module Type
|
|
Communication Interface
|
Button / RS232 or USB communication |
|
Synchronous Electrical Signal Interface
|
SMA |
|
Power Supply
|
12V DC, <20W |
|
Size
|
200(W)×145(D)×65(H)mm |
|
Operating Temperature
|
5 ~ 35°C |
|
Operating Humidity
|
0~70% |
