Short Wavelength Laser 375nm 50mW UV Laser CW and Modulation Together

$7,235.00

Add to Cart:


Short Wavelength Laser 375nm 50mW UV Laser CW and Modulation Together

[Note]
This laser spot is an ellipse spot.
If you need a circular spot, you can customize the coupling fiber laser.

[Features]
1.High power stability(<3%)
2.Small volume, easy to install

[Specifications]
Product Name: 375nm UV Laser
Lead Time: 1~3 weeks, Custom product available!
Wavelength: 375nm  (+/-5nm)
Output Power: 50mw
Operating Temperature: 0°C-40°C
Storage Temperature:  -40°C-85°C

Parameter Work condition Symbol Min Type Max Unit
Output Power @PO PO     50 mW
Power Stability 2hrs Ps     3 %
Central Wavelength @PO λc   375   nm
Spectral linewidth @PO FWHM   2   nm
Beam Diameter 1/e2 Full angle D   2mm  D//
1mm  D┴
  mm
Beam Divergence Angle  1/e2 Full angle Div   0.5 mrad Div//
1 mrad Div┴
  mrad
Warming Time @PO Tw     5 min
Noise RMS(10Hz-100MHz) N   1   %
Service Life @PO MTBF 10000     hrs


375nm UV laser

375nm UV laser

375nm UV laser
