793nm 795nm 1~500W Fiber Coupled Laser PC Control IR Laser System Customizable

$100.00

Add to Cart:


793nm 795nm 1~500W Fiber Coupled Laser PC Control IR Laser System Customizable


Note: The $100 is the deposit, not the final price.

[Features]
1. Laser + laser drive + temperature control system, integrated laser source, high reliability.
2. Universal control interface
3. 8 hours power stability less than 3%.
4. Laser long service life, >10000 hours.
5. Output wavelength can be set by temperature control
6. Anti-lightning, anti-static, sound over-current protection, over-temperature protection, anti-reverse protection.
7. High output power, the power and spectral stability is high.
8. Simple to use, allowing customers to quickly integrate systems.
9. Can be customized according to customer requirements.

[Specification]
Product Name: Fiber Coupled Laser System
Laser Mode: Module type-1 /Module type-2 /Chassis type-1 /Chassis type-2  /Chassis type-3 (Choose)
Wavelength: 793nm
Output Power: 1~500W (customizable)
Wavelength Range: ±5nm / ±10nm / ±20nm
Coupling Method: Single tube / multiple tubes / with indicator light
Wavelength Temperature Coefficient: ~1nm/°C
Fiber Core Diameter: 105µm /200µm /400µm (Choose)
Numerical Aperture: 0.22
Fiber Connector: SMA-905 / FC/PC (Choose)
