Hitachi 639nm 210mW Orange-red Laser Diode HL63023DG LD Without PD TO-5.6mm

Hitachi 639nm 210mW Orange-red Laser Diode HL63023DG LD Without PD TO-5.6mm

[Features]
Optical output power: 210mW
Wavelength: 639nm Typ.
Low operating current: 225mA at 200mV
High Wall plug efficiency: 33%
Single transverse mode
TE mode oscilation
Φ5.6mm CAN Package

[Applications]
Leveler
Show Laser
Medical
Laser module
Measurement
Light source of optical equipment

[Specification]
Product Name: Laser diode
Model NO: HL63023DG
WavelengthL 639nm
Output Power: 210mW
Package: TO- Φ5.6mm
Power Supply Voltage: 2.7V
Working Life: 20,000 hours
Working Temperature: -40~+60℃
Storage Temperature: -40~+85℃
Laser Diode (LD) Reverse Voltage: 2V
