C-band 400mW~800mW Fiber Raman Amplifier

Starting at: $8,199.00  $1,912.00
Save: 77% off

Please Choose:



Add to Cart:


The fiber Raman amplifier is designed for optical signal amplification of long-haul optical transmission systems and dense wavelength division multiplexed optical transmission systems. Gain flat, low noise amplification is achieved for optical signals in the C-band or C+L bands. The status parameters and configuration information of the module can be monitored in real time by the host computer software, and the factory parameters can be preset according to customer requirements. It is compact and easy to integrate, and can also be supplied in a desktop package according to customer needs.



Fiber Raman Amplifier
Characteristic:

  1. small modular design
  2. wide wavelength range
  3.  high gain, gain flatness
  4. low noise index, low power consumption

Application:

  •  long distance optical communication network
  •  optical fiber sensor
  •  fiber laser

Parameter index:



Parameter index

Unit

Minimum value

Typical value

Maximum value

Remarks

Wavelength range

nm

1528

1550

1565

C-band

C+L band can be customized:1528~1604

Raman gain

dB

10

15

22



Gain flatness

dB





1



Pump power

mW



400~800mW



Choose

Polarization dependent gain

dB



0.3



Polarization mode dispersion

ps





0.5



Input / output isolation

dB

40







Noise index

dB



0



Operating temperature range

°C

-20



+65



Working humidity range





70



Power supply type



DC+5V or DC +48V or AC 110v~220V



Pigtail connector type



FC/APC adapter or Customized



The input and output of fiber types



Ordinary single-mode fiber SMF-28



Size

mm

260(W)×320(D)×120(H)



Work mode



ACC:Constant pump current;

APC:Constant output power

Power monitoring with input and output
